Product Details

The product name

10.1 inch TFT LCD moudule

Display model

C101EAN01.0-42-JWS

Display Resolution

 1280(RGB)×720

Aspect Ration

  169

Contrast

1000:1 (Typ.) (透射)

Overall Size

234.9(W) × 143.0(H) * 4.35(D)

Active Area (A.A)

223.68 (H)125.82 (V)

Luminace

550cd/m²

Visual Angle

80/80/80/80

Viewing Direction

6 Oclock

Color Depth

16.7M , 60%

Module weight

187g

Interface

LVDS(1 ch, 6/8-bit) , FPC , 40 pins

Drive-screen voltage

19.6V

Backlight Supply Current

140 mA



Operating temperature range

 -25 ~ 75 °C

Storage temperature range

 -35~ 85 °C

Response Time

10/15 (Typ.)(Tr/Td) ms

Display mode

AHVANormally BlackTransmissive
