6.2 inch

/ueditor/net/upload/image/20180919/6367296845027315573229058.jpg
/ueditor/net/upload/image/20180919/6367296845677298931109938.jpg
/ueditor/net/upload/image/20180919/6367296847506939598453702.jpg
节点内容
Product Details

The product name

6.2 inch TFT LCD moudule

Display model

JWS062IDW1-21L

Display Resolution

800(RGB)×480

Aspect Ration

 16:9

Contrast

600:1 (Typ.) (TM)

Overall Size

155.2(W)×88.2(H) ×5.3(T)

Active Area (A.A)

137.52(W) x 77.232(H)

Luminace

400 cd/m²

Visual Angle

75/75/70/70

Viewing Direction

6 o'clock

Color Depth

262K/16.2M , 50%

Module weight

120.0g

Interface

60 pins Parallel RGB (1 ch, 8-bit)

Drive-screen voltage

9.9V

Backlight Supply Current

140mmA

Operating temperature range

   -20 ~ 70 °C

Storage temperature range

   -30 ~ 80 °C

Response Time

10/15 (Typ.)(Tr/Td) ms

Display mode

TNMormally WhiteTransmissive
